CC5048DC Diesel Walk-Behind Core Saw for Deep, High-Torque Cutting

Description

DIAMOND PRODUCTS CC5048DC CORE CUT SAW

BLADE NOT INCLUDED, AVAILABLE SEPARATELY

Features & Benefits

• Certified EPA / CARB Tier 4 Engine for clean reliable power with Caterpillar’s latest engine technology
• Up to 17.5″ deep sawing with 42″ blade and 7″ quick disconnect flanges
• Adjustable blade lowering speed that is dash mounted for quick precise adjustment
• Single hand sawing control with forward / reverse / raise / lower all in one ergonomic grip
• Three position handle bars set and lock at comfortable, preferred angles
• Large 6 gallon fuel tank with convenient left side filler door along with electronic low fuel level indication
• Quick access rear cover screen for inspecting and service with simple latch convenience
• Heavy duty wheels with durable polyurethane tread on front and thick rubber tread on the rear
• Automatic parking brake with hydraulic activation in stop position gate
• Robust blade shaft offers reliable support from 2 pillow block style, precision ball bearings
• Spline drive PTO gives precision zero side load drive to dampen vibration and shock loads
• Advanced air cleaner with radial seal primary and secondary filters with maintenance indicator
• Sealed electronics protection resists heat, moisture, shock and vibration

Advanced Digital Display

Enhanced, rich color graphics for superior visibility in sunlight.  Three view modes to choose from: blade speed, engine speed and engine torque.  Blade overspeed alert that warns of blade RPM exceeding safe limit.  Engine service alerts offer maintenance reminders for optimum engine function.

Includes: Telescoping front and rear pointers, fuel cooler, low coolant level sensor, oil drain valve, air restriction indicator, travel speed push/pull cable, positive front axle depth stop, slip-on blade guard flange, polycarbonate decals, blade shaft wrench

CC5048DC SPECIFICATIONS
